FEATURES
- With auto memory function after Power restart
- Full Power charging
- 6V / 12V 1A for motorcycle batteries
- Selective mode for AGM and Winter condition
- Fit for Lead Acid / AGM and Gel Batteries
| Model | 6V/12V 4.5A |
| Input Voltage | 100-240VAC/50Hz |
| Input Cable | With Cable (Desktop Case) |
| Charging Battery Type | 12V Lead-Acid: 1.2AH – 120AH; 6V Lead-Acid: 1.2AH – 14AH |
| Restore Dead Battery Function | 6V &12V Battery |
| Abnormality Protection | Short Circuit; Battery Defective and Reverse Connection |
| Charging Mode | 6 Steps With Fully Automatic Switch Mode |
| Material Of Housing | UV Resistant Polycarbonate |
| Proof Water Grade | IP65 |
| Approval | CE / GS |
| Application | Used in Car, Motorbike, Vehicles |
Specification
| MODEL | PL-C004P | PL-C002P | PL-C001P |
| Charging current (A) | 4.5Amp | 2Amp | 1Amp |
| Charging voltage (V) | 6V / 12V | 6V / 12V | 6V/12V |
| For battery: | |||
| Open WET | √ | √ | √ |
| Maintenance free | √ | √ | √ |
| AGM/VRLA | √ | √ | √ |
| Calcium | √ | ||
| To charge battery capacity | 14Ah - 120Ah | 1.2Ah - 40Ah | 1.2-24Ah |
| To maintain battery capacity | 14Ah - 150Ah | 1.2Ah - 60Ah | 1.2-24Ah |
| Microprocessor controlled | √ | √ | √ |
| Charging steps: | |||
| Float charge | √ | √ | √ |
| Overcharge protection | √ | √ | √ |
| Allow for safe contiounus charge | √ | √ | √ |
| Boost | |||
| Recovery function | √ | √ | √ |
| IP rating | |||
| Charge Status indiations: | |||
| Battery defect | √ | √ | √ |
| Wrong connection | √ | √ | √ |
| Wrong polarity | √ | √ | √ |
| Short circuit | √ | √ | √ |
| Charging progress indication | √ | √ | √ |
| Full charge indication | √ | √ | √ |
| 230V power on | √ | ||
| built-in protection | √ | √ | √ |
| EMC free | √ | √ | √ |
| Reversed polarity Protection | √ | √ | √ |
| Short-circuit-protection | √ | √ | √ |
| Spark free protection | √ | √ | √ |
| Mechanical features | |||
| Length of Dc cables | |||
| Length of AC 230V cable | |||
| DC charging clips fully insulated | |||
| Material of housing | |||
| Fire retardant material | |||
| Dimensions | 193.5x66.4x46mm | 100x71x73mm | |
| weight | 193.5x66.4x46mm |
